01
Battery powered
15.0 V, 1500 mAh on-board cell. No console, no cable, no capital equipment — the morcellator is the system.
Introducing · Morcellator VX-1
Precision morcellation, reimagined for single-use.
A battery-powered disposable morcellator engineered for laparoscopic gynecologic procedures — purpose-built for hysterectomy and myomectomy. Sterile from the first incision. Discarded after the last.
Ergonomic handle
Cutting sleeve
Obturator
Coreguard
The device
The Morcellator VX-1 — a complete, self-contained system shipped sterile, used once, retired safely.
Morcellator VX-1 · F240115150
Disposable Morcellator VX-1
Battery-powered cutting and tissue extraction in a single pistol-grip instrument. Integrated trocar and obturator. Pre-configured "Safety Guard," "Cut 1" (peel) and "Cut 2" (core) modes.
- Cutting sleeve Ø 12–14 mm incision
- Operation Non-continuous
- Power 15.0 V · 1500 mAh
- Max speed 1000 RPM
- Sterilization Ethylene oxide
- Shelf life 36 months
DISPOSABLE · STERILE
F240115150
VENTURIS MEDICAL
REV. B0 · 2024.3
Anatomy
Eight components.
One sterile, single-use instrument.
01
02
03
04
05
06
07
08
01
Insulating sheet
Electrical and thermal isolation along the cutting tube.
02
Adjuster cap
Threaded cap controlling the coreguard depth setting.
03
Bracket
Locks the trocar between Safety Guard, Cut 1 and Cut 2 positions.
04
Handle
Ergonomic pistol grip housing the 15.0 V battery and electronics.
05
Trigger / Button
Single-action activation of the rotating cutting blade.
06
Cutting sleeve
Rotating tubular blade — 1000 RPM peel and core action.
07
Coreguard
Adjustable barrier preventing over-travel of the cutting tip.
08
Obturator
Inserted fully prior to trocar placement through the abdominal wall.
Engineered for confidence
Six decisions, made before the first incision.
02
1000 RPM cutting tool
Tubular peel-and-core blade with two distinct positions — "Cut 1" for peeling, "Cut 2" for coring tissue.
03
EO sterilized
Single sterile-barrier system with protective outer packaging. Validated ethylene-oxide cycle. Three-year shelf life.
04
Single-use only
No reprocessing, no resterilization, no cross-contamination risk. Each device retires immediately after the procedure.
05
Integrated obturator
The obturator and trocar arrive pre-paired. Inserted under direct visualization through a 12–14 mm incision.
06
Compliant by design
Conforms to IEC 60601-1-2 : 2014 + AMD1 : 2020 EMC. Type BF applied part. Latex-free. RX Only.
Specifications
The numbers, on record.
Model
F240115150
Operation mode
Non-continuous
Nominal voltage
15.0 V
Nominal capacity
1500 mAh
Maximum speed
1000 RPM
Waterproof
IPX0
Sterilization
EO
Shelf life
3 years
Storage temperature
−20°C → +50°C · RH ≤ 80%
Compliance
IEC 60601-1-2 : 2014 + AMD1 : 2020 · Type BF · Class A · Latex-free · RX Only
Intended use
Designed for two procedures.
Specified for both.
Hysterectomy
Laparoscopic removal of the uterus, with morcellation of de-vascularized, dissected tissue under direct visual control.
Myomectomy
Removal of uterine fibroids, with controlled coring ("Cut 2") and peeling ("Cut 1") of de-vascularized myomas.
Important contraindications
Per FDA guidance (Dec 30, 2020), laparoscopic power morcellators are contraindicated for removal of uterine tissue containing suspected fibroids in patients who are post-menopausal or over 50, or who are candidates for en-bloc tissue removal through the vagina or via a mini-laparotomy incision. Tissue must be devascularized and dissected before morcellation. Not for use where malignancy is known or suspected.
RX Only · For use by trained surgical professionals.
Catalog · Coming soon
More instruments,
built on the same disposable platform.
Coming soon
Hysteroscope Sheath
Disposable gynecology hysteroscope sheath.
Coming soon
Smoke Filter
Disposable surgical smoke evacuation filter.
Coming soon
Bladder Evacuator
Single-use evacuation device for urological procedures.
Coming soon
Irrigation Tubing
Disposable irrigation tubing set for surgical fluid management.
Prescription
Ethylene oxide
Type BF
Single use
Latex free
EMC compliant
